The Ground Zero GZRM 80SQX is a compact 80-mm midrange driver from the RADIOACTIVE series, designed to deliver clean and detailed reproduction of the crucial midrange. With its anodized aluminum cone, it combines low moving mass with high stability, thereby creating ideal conditions for precise and controlled music reproduction.

For the driver, Ground Zero relies on a high-performance neodymium magnet. The compact design also makes installation easier in tight spaces. A 25-mm voice coil converts the audio signal and enables a power handling capacity of 50 watts RMS or 80 watts peak.

A distinctive feature of the SQX model is its low-resonance aluminum basket. It provides a stable foundation for the speaker system and reduces unwanted mechanical influences on the diaphragm’s movement. With an installation depth of just 37 mm, the GZRM 80SQX is particularly well-suited for high-end car audio installations where compact dimensions are essential.

With an impedance of 3 ohms, a sensitivity of 89 dB, and a specified frequency range of 140 Hz to 4 kHz, this midrange driver can be easily integrated into multi-way systems. It is connected via solder terminals. Matching protective grilles are also included.

The GZRM 80SQX is sold in pairs and is particularly well-suited for sound-oriented front speaker systems as well as custom-built 3-way and multi-way car hi-fi systems.

Technical Specifications

Manufacturer: Ground Zero
Model: GZRM 80SQX
Series: RADIOACTIVE
Speaker Type: Sound-Quality Midrange Speaker
Nominal diameter: 80 mm / 3.15 inches
RMS Power Handling: 50 watts
Maximum power handling: 80 watts
Impedance: 3 ohms
Efficiency: 89 dB
Frequency response: 140 Hz – 4 kHz
Resonance frequency (Fs): 138 Hz
Voice coil diameter: 25 mm / 1 inch
Diaphragm material: Anodized aluminum
Magnet material: Neodymium
Cage: Low-resonance aluminum cage
Installation diameter: 77 mm
Installation depth: 37 mm
Connection: Solder connection
Protective grille: Included in the package
Packaging unit: 1 pair / 2 speakers

Highlights

Compact 80-mm midrange driver for sound-oriented car audio systems
Rigid, lightweight diaphragm made of anodized aluminum
High-performance, compact neodymium motor
Sturdy, low-resonance aluminum basket
25-mm voice coil
Installation depth of only 37 mm
3-ohm version
Protective grille included
Sold as a pair

What's Included:
2x Ground Zero GZRM 80SQX midrange drivers, including protective grilles
