The CZ Audio SQ6.5 is a high-quality 16.5-cm low-midrange driver designed for demanding car audio and sound quality systems. Its exceptionally rigid all-aluminum cone combines precise sound reproduction with high mechanical stability, making it suitable for both finely tuned audio systems and applications requiring higher volume levels.

The driver features a long 25-mm voice coil, which enables a linear diaphragm excursion of up to ±5 mm. This allows the SQ6.5 to deliver powerful performance even in the lower frequency range and provides a solid foundation for dynamic integration with a subwoofer.

A pole plate with multiple drill holes aids in heat dissipation from the drive system and improves thermal performance during prolonged use. In addition, the speaker features a copper pole capsule, which helps linearize the impedance response. The butyl rubber surround ensures controlled cone movement, while the powder-coated and damped steel basket provides a stable foundation.

With a nominal impedance of 4 ohms and a power handling capacity of 70 watts RMS, the CZ Audio SQ6.5 is ideal for use with high-quality car audio amplifiers or DSP power amplifiers.

Technical Specifications:

Manufacturer: CZ Audio
Model: SQ6.5
Speaker Type: Mid-bass driver
Nominal size: 16.5 cm / 6.5 inches
Diaphragm diameter: 165 mm
Diaphragm material: All-aluminum
Nominal impedance: 4 ohms
DC resistance (Re): 3.3 ohms
RMS Power Handling: 70 watts
Frequency range: 80 Hz – 5,000 Hz
Linear frequency response: 80 Hz – 5,000 Hz (±3 dB)
Resonance frequency (Fs): 80 Hz
Efficiency / Sound Pressure: 88 dB (1 W / 1 m)
Voice coil diameter: 25 mm
Linear diaphragm stroke (Xmax): ±5 mm
Bead: Butyl rubber
Basket: high-damped steel basket
Basket surface: black powder-coated
Base plate: drilled multiple times for improved heat dissipation
Copper-pole capsule for linearizing the impedance response
Connections: gold-plated speaker terminals
Installation depth: 65 mm
Total depth: 71 mm
Application: Car Audio / Sound Quality
