B² Audio Rage2300.2
Regular price
From
750,00€
Unit price
/
Unavailable
Perfection, performance & prestige.
The Rage series from B² Audio combines price and performance at the highest level. A series that meets a high standard visually, technically and functionally. The Rage amplifiers are characterized by enormous power in the smallest of spaces, despite their very elegant design.
To avoid problems with cooling, B2 Audio uses a specially designed cooling system to optimally dissipate heat. The large power terminals also provide a sufficient power supply. With a cross-section of up to 50mm², a very good power supply can be guaranteed here. Thanks to the digital technology and the very high efficiency of the RAGE 2300.2, a high output power can be generated with low power consumption.
The RAGE 2300.2 is suitable for larger loudspeaker systems with at least 2 Ohm connection per channel or can drive subwoofers with up to 2300 watts RMS at 4 Ohm bridge without hesitation. The optional bass control allows infinitely variable bass control, and the control also includes voltage monitoring and a clipping indicator.
| Technical data: | RAGE 2300.2 |
| FQ range: | 10 Hz ~ 27 KHz |
| Signal-to-noise ratio: | >95 dB |
| Input sensitivity: | 5V ~ 0.2 V |
| LPF 24 dB/ Oct: | 50 Hz ~ 5 KHz |
| HPF 24 dB / Oct: | 30 Hz ~ 5 KHz |
| Attenuation factor: | >200 |
| Current input: | 50mm² |
| Fuse recommendation: | 250 A |
| Voltage range: | 9 V ~ 16 V |
| Dimensions in inches: | 12" x 7.87" x 2.75" |
| Dimensions in cm: | 305 x 200 x 70 MM |
| Power @ 4 Ω 13.8 V: | 2 x 600 w |
| Power @ 4 Ω 14.4 V: | 2 x 650 w |
| Power @ 2 Ω 13.8 V | 2 x 1100 w |
| Power @ 2 Ω 14.4 V: | 2 x 1150 w |
| Power @ 4 Ω bridge 13.8 V: | 1 x 2200 w |
| Power @ 4 Ω bridge 14.4 V: | 1 x 2300 w |
