Audio System H33 EVO
Regular price
5.999,00€
Unit price
/
Unavailable
The Audio System H33 EVO is an SPL subwoofer designed without compromise for extreme sound pressure applications and professional show vehicles. With its massive 33-inch diameter (84 cm), an extremely durable dual voice coil, and a design engineered for maximum stability, it delivers brutal bass performance even under the harshest conditions. The combination of an ultra-stable KPC paper cone, a high-efficiency magnet, and a sophisticated venting system ensures high efficiency, impressive control, and exceptional long-term durability. The H33 EVO is designed for ambitious car audio enthusiasts who refuse to compromise on volume, bass depth, and performance.
Technical Specifications
- 84 cm (33") SPL Power Subwoofer
- H-EVO Series
- RMS power: 2 × 2,500 watts
- Music output: 2 × 5,000 watts
- Peak power: up to 20,000 watts at 50 Hz
- Impedance: 2 × 1 ohm
- 6" (152 mm) flat-wire dual voice coil, “Made in the USA”
- High-Efficiency Magnet (HEM)
- 20-fold ventilation system for optimal cooling
- Ultra-stable KPC paper membrane
- Pure Carbon Dust Cap
- Flow-optimized cast aluminum basket
- Double-stitched, highly flexible foam surround
- Woven double silver braids
- Progressive 6-speed PPTA Connex Spider
- USS (Up Stroke Spacer) for maximum travel
- Outer diameter: 840 mm
- Installation diameter: 771 mm
- Installation depth: 420 mm
- Weight: approx. 39 kg
Highlights
- Designed for uncompromising SPL and competition applications
- Extremely high power handling capacity for high-performance amplifier systems
- Robust construction for maximum stability at extreme sound levels
- Efficient cooling thanks to a sophisticated multi-ventilation system
- High excursion and precise bass reproduction despite enormous power
- Ideal for custom high-end show cars and SPL projects
