AudioControl EPICFIVE
Regular price
369,00€
Unit price
/
Unavailable
Tax included
Shipping calculated at checkout.
AudioControl EPICFIVE - Single is backordered and will ship as soon as it is back in stock.
Free shipping from 49€
Free shipping from 49€
Shipping
✓ Free shipping from 49€ within Germany and from 99€ to the EU.
✓ Delivery times vary depending on the product and can be found on the product page, usually 1 - 3 working days for stock items, international shipping times vary, usually 6 - 10 working days.
✓ In most cases, shipping is carried out by DHL, UPS and GLS.
✓ Depending on the product and location, items can also be shipped with other providers.
✓ Tracking will be sent by email after the shipment has been processed.
Normal shipping route
✓ 1 - 40Kg = DHL, UPS and GLS
✓ 40.1 - maximum kg = forwarding agency
✓ Bulky goods = freight forwarder
✓ Customs shipments = DHL, GLS or freight forwarder
Parcel collection
✓ Collection takes place regularly from Monday to Friday, orders received by 3 p.m. are usually disposed of on the same day for goods in stock and transported directly to the parcel center.
5% discount for prepayment
5% discount for prepayment
Receive a 5% pre-payment discount. The discount is automatically deducted in the shopping cart/checkout and is valid for all products. Vouchers or discount codes may be excluded or already combined.
Wiring wizard & port computer
Wiring wizard & port computer
Use our wiring wizard for simple wiring of speakers and subwoofers! The correct connection is important for your amplifier! Low-impedance operation can damage the amplifier! The data sheet shows you which connection the respective amplifier is designed for!
Our port calculator shows you which tuning your enclosure has! The net volume is always particularly important here; calculate the pure chamber of the subwoofer beforehand to arrive at the correct result. The net volume is calculated minus all displacements and is important when designing the enclosure.
Downloads
Downloads
Manufacturer Information
AudioControl EPICFIVE
Regular price
369,00€
Unit price
/
Unavailable
The AudioControl EPIC Series 5-channel amplifier delivers first-class sound in a compact, thermally efficient design - and at an unbeatable price. Thanks to its high current Class D technology, it ensures maximum output power with high efficiency. Combined with the separately available Epicenter Bass Restoration Processor, it takes your bass experience to a new level. This amplifier offers exceptional sound quality at an excellent price and is the only AudioControl amplifier with a bass control for convenient control.
Digital Class D amplifier: Powerful yet compact, designed for 2-ohm loads and high output power.
Variable bass boost (0-12 dB): Selects the frequency to be boosted.
Direct wire terminals with hex screws: Ensure solid and reliable connections.
4-Gauge power connector and 8-gauge speaker connector: Designed for maximum current flow.
Signal-to-noise ratio of over 91 dB (according to CEA standard): Extremely low power consumption in idle mode (< 0.5-1 A).
Intelligent automatic reset protection: Multiple protection modes prevent damage if a problem occurs with your amplifier:
Output overcurrent protection (OCP)
Input overvoltage protection (OVP)
Input undervoltage protection (UVP)
Output DC offset protection (DCP)
Overtemperature protection (OTP)
Includes ACR-E remote control button
THE EPICENTER LINK: Simplify your installation by connecting the EPIC amplifier directly to an EPICENTER bass restoration processor.
Features:
✓ Compact high power class D amplifier
✓ High current design
✓ 4 x 75 watts + 1 x 300 watts into 4 ohms
✓ 4 x 150 watts + 1 x 500 watts into 2 Ohm
✓ 1 x 700 Watt into 1 Ohm
✓ 2 x 300 Watt into 4 Ohm bridged
✓ Intelligent protection circuit with automatic reset
✓ Variable Linkwitz-Riley high/low pass filter (12 dB/octave)
✓ Variable subsonic filter (12 dB/octave)
✓ Robust power/speaker connections with hexagon socket screws
✓ Developed for THE EPICENTER®
Technical data:
INPUTS
Line level inputs: 500 mV - 12 V RMS
OUTPUTS
Continuous power (RMS) at 14.4 V
4 x 75 watts + 1 x 300 watts @ 4 ohms
4 x 150 watts + 1 x 500 watts @ 2 ohms
1 x 700 watts @ 1 ohm (subwoofer output)
2 x 300 watts @ 4 ohms bridged
WEIGHTS & DIMENSIONS
DIMENSIONS: 15.5 cm W x 33.9 cm L x 5.1 cm H
PERFORMANCE
Frequency response (+/- 1 dB):
10 Hz - 24 kHz (channel 1/2/3/4)
12 Hz - 181 Hz (channel 5)
Signal-to-noise ratio:92.1 dBa, reference power 75 watts into 4 ohms
Power/ground wire cross-section: 4 AWG
Recommended fuse rating: 150 amps
High-pass filter: 12 dB/octave Linkwitz-Riley, Off, 50 Hz to 500 Hz
Low-pass filter: 12 dB/octave Linkwitz-Riley, 40 Hz to 180 Hz
Subsonic Filter: 12 dB/octave Linkwitz-Riley, Off to 50 Hz
EPIC Boost: Center Frequency: 45 Hz, Gain: 0 to 12 dB
Wire Size for Speaker Connections: 8 AWG
INCLUDED: EPICFIVE, wrench, screws, ACR-E remote with cable, Epicenter Link (1 meter cable harness), owner's manual, warranty.
